Low Pressure 1Mpa 1tph Coal Fired Steam Boiler Horizontal Type

Product Categories
Taikang Yinyu Boiler Manufacturing Co., Ltd
Contact Now

Low Pressure 1Mpa 1tph Coal Fired Steam Boiler Horizontal Type

  • 1
  • 2
  • 3

Brand Name : Yinyu

Model Number : DZH/DZL

Certification : ISO9001/BV

Place of Origin : Henan China

MOQ : 1

Price : $5,000.00-$10,000.00

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100 Qty/per month

Delivery Time : 7-30 work days

Packaging Details : Loose package

Name : Coal Fired Steam Boiler

Manufacture : Yes

Thermal efficiency : 82%-84%

Feature : Low Pressure

Quality Guarantee : 1 year,Lifetime maintain commitment

Condition : New

Material : GB/T 3087-2008

Application : Industries

Type : Horizontal Type

Output : Steam

Contact Now

Low Pressure 1tph Coal Fired Steam Boiler Horizontal Type

Feature


  • Compact design: Boiler has advantages of compact structure, the reasonable water cycle design, and quick start;
  • Advanced chain grate: The advanced chain grates assure reliable operating, less coal missing and energy-saving also reduce installation and maintenance workload of the grate; using a long arch, increasing the effective area of grate, good coal adaptability and fuel burning fully;
  • High efficiency: Grate with reasonable combustion air distributor makes fuel burning fully and improves machine efficiency;
  • High quality steam: steam drying degree of 96% or more;
  • High intelligent control: The boilers have the pressure, temperature, water and other multi-chain security control; a high degree of mechanization, simple and convenient operating;
  • Easy to install: The boiler is transported in integrated form from factory that makes the installation period short. The boiler is very popular for our customer by its compact structure, beautiful appearance, bright color and luster.


Product parameters

DZH1-1.0SCI

NO;NameUnitNumberDescription
1Rated outputt/h1
2Rated working powerMpa1.0
3Rated steam pressure℃184
4Heating area㎡39.4
5Grate area㎡1.9
6Design fuels/Biomass,coal,rice husk...
7Bulk sizemm3900×1840×3120


DZH2-1.25SCI


NO;NameUnitNumberDescription
1Rated outputt/h2
2Rated working powerMpa1.25
3Rated steam pressure℃194
4Heating area㎡73.6
5Grate area㎡3.74
6Design fuels/Biomass,coal,rice husk...
7Bulk sizemm4500×2240×3320


DZL4-1.25SCI


NO;NameUnitNumberDescription
1Rated outputt/h4
2Rated working powerMpa1.25
3Rated steam pressure℃194
4Heating efficiency%80
5Grate area㎡5.18
6Design fuels/Biomass,coal,rice husk...
7Fume temperature℃169
8Bulk sizemm6470×2820×3668


DZL6-1.25SCI


NO;NameUnitNumberDescription
1Rated outputt/h6
2Rated working powerMpa1.25
3Rated steam pressure℃194
4Heating efficiency%80
5Grate area㎡7.55
6Design fuels/Biomass,coal,rice husk...
7Fume temperature℃166.3
8Bulk sizemm8244×2951×3550

Low Pressure 1Mpa 1tph Coal Fired Steam Boiler Horizontal Type
Low Pressure 1Mpa 1tph Coal Fired Steam Boiler Horizontal Type
Our services


Pre-sale service:
We help customer choose the best boiler model according to
different requirements of various industry. Before delivery we
will provide foundation drawing, layout drawing, boiler room
layout, etc.
In-sale service:
We keep 24 hours online and keep close contacts during the
production process to ensure on time delivery with perfect
finished product.
After-sale service:
1. provide full range of original spare parts.
2. Engineers abroad installation and commissioning service is
available.
3. Our engineers will held a training for boiler workers to
ensure the safe operation.
4 .Free maintenance and repair for one year and lifelong
service.
